1. Definition:
A Short Bend 45° is a pipe fitting used to change the direction of flow in a pipeline by 45 degrees. Its compact design makes it suitable for installations where space is limited.
2. Material:
-
Mild Steel (MS): Offers durability, good mechanical strength, and resistance to moderate pressure and temperature. Ideal for industrial piping applications.
3. Key Features:
-
Allows smooth directional change in pipelines with minimal pressure loss.
-
Compact design suitable for space-constrained areas.
-
Can handle medium-pressure and medium-temperature applications.
-
Durable and corrosion-resistant with proper maintenance.
4. Applications:
-
Oil & gas pipelines
-
Petrochemical and chemical plants
-
Power plants
-
Water supply and wastewater systems
-
General industrial piping
5. Standards & Sizes:
-
Manufactured as per ANSI/ASME B16.9 or equivalent standards.
-
Sizes typically range from 1/2” to 48” depending on requirement.
