🔧 CI-18 Cast Iron Ball Valve
-
Product Standard: IS:9890 Class 125
-
Pressure Rating: PN 16
-
Body Material: Cast Iron IS:210 Gr.FG220
-
Design: Three-piece construction
-
Seat Type: Renewable Teflon
-
Trim Materials:
-
Ball: Stainless Steel AISI-304
-
Stem: Stainless Steel AISI-410
-
-
Gland Packing: Teflon Rings
-
End Connections: Flanged (as per IS:3516-1966 undrilled / BS10 Table F)
-
Testing:
-
Body Test Pressure: 300 Psig (21 bar g) Hydraulic
-
Seat Test Pressure: 220 Psig (15.4 bar g) Hydraulic, 100 Psig (6.9 bar g) Air
-
-
Applications: Suitable for water, oil, and gas systems
📏 Dimensions (in mm)
| Nominal Size (Inches) | F (Face to Face) | LL (Approx.) |
|---|---|---|
| 1/2 | 130±2 | 135 |
| 3/4 | 130±2 | 160 |
| 1 | 140±2 | 170 |
| 1 1/4 | 165±2 | 205 |
| 1 1/2 | 165±2 | 205 |
| 2 | 203±2 | 205 |
| 2 1/2 | 222±2 | 250 |
| 3 | 241±2 | 380 |
| 4 | 305±2 | 380 |
