Champion Style 51 is a high-pressure compressed fibre gasket sheet manufactured from premium-grade fibre with specialized elastomers, fillers and binders. It is designed for demanding high-pressure gas and steam applications and other industrial services involving elevated temperature and pressure. Construction Compressed fibre jointing material Specialized elastomeric binder system Available in non-metallic and metallic versions Metallic version incorporates steel-wire gauze reinforcement Graphited anti-stick finish is available on the metallic version. Temperature & Pressure Rating Type Maximum Continuous Temperature Maximum Pressure Non-Metallic 440°C 8 MPa / 80 bar Metallic 480°C 10 MPa / 100 bar Actual suitability depends on the combined pressure-temperature conditions and chemical compatibility. Typical Physical Properties Density: 1.9–2.2 g/cm³ Tensile Strength: ≥15 MPa Compressibility: 7–12% Stress Relaxation: ≥23 MPa Gas Permeability: <0.5 cc/min Recovery: ≥45% Ignition Loss: ≤22% Available Thicknesses 0.5 mm 0.75 mm 1.0 mm 1.5 mm 2.0 mm 3.0 mm 4.0 mm* 5.0 mm* *Certain thicker sizes have limited sheet-size availability. Applications High-pressure steam lines Petrochemical plants Refineries Process industries Petroleum distillate services Neutral non-flammable gases Oils and fats Alcohols and motor fuels Alkali and dye applications, subject to compatibility. Features & Advantages Suitable for demanding temperature and pressure conditions Good compressibility and recovery Low gas permeability Reliable sealing performance Metallic version provides additional mechanical strength Available as full sheets or pre-cut gaskets Complies with IS 2712:1998 Grade W/2 and other listed specifications.

Champion Style 54 Super is a premium-grade compressed fibre jointing sheet designed for demanding high-temperature and high-pressure sealing applications. It is especially used for superheated steam and is also suitable for several compatible industrial fluids. It is available in non-metallic and steel-wire-reinforced metallic versions. Construction Premium-grade fibre with heat-resistant fillers and binders Non-metallic version: Yellow Metallic version: Steel-wire gauze reinforced, minimum 18 mesh × 30 gauge Metallic version supplied with a smooth anti-stick graphite finish Metallic identity colour: Graphited black Temperature & Pressure Rating Type Maximum Continuous Temperature Maximum Pressure Style 54 Super Non-Metallic 550°C 15 MPa / 150 bar Style 54 Super Metallic 600°C 16 MPa / 160 bar Actual operating limits should always be selected according to the pressure-temperature combination and service conditions. Typical Physical Properties Density: 2.0–2.2 g/cm³ Tensile Strength: ≥28 MPa Compressibility: 7–11% Recovery: ≥50% Gas Permeability: <0.5 cc/min Ignition Loss: ≤25% Available Thickness 0.5 mm 0.75 mm 1.0 mm 1.5 mm 2.0 mm 3.0 mm 4.0 mm 5.0 mm Applications Superheated steam lines Boilers Steam systems Air separation units Petroleum distillate services Oil refineries Diesel generators Marine engines Hydrocarbon, gas, solvent and alcohol services, subject to compatibility Features & Advantages Excellent resistance to high temperature and pressure Good sealing and recovery properties Suitable for demanding steam applications Metallic version provides additional strength under severe conditions Performs well where pressure fluctuates and vibration is present Available as sheets and pre-cut gaskets in custom shapes and sizes

Champion Cut Gaskets are ready-to-use gaskets cut from compressed fibre jointing sheets into the required size and shape. They are used to seal flange joints, valves, pumps, pipelines, heat exchangers, and other industrial equipment. The exact performance depends on the Champion sheet grade selected, such as Style 20 Red or Style 20 Metallic. Typical Construction Base Material: Compressed fibre jointing material Reinforcement: Non-metallic or steel wire-reinforced, depending on grade Surface Finish: Anti-stick graphite finish on selected grades Shape: Full Face / Ring Type / Custom Shape Manufacturing: Die-cut or precision-cut as per flange dimensions Typical Sizes & Thickness Champion Style 20 material is available for cutting into custom gaskets, with common sheet thicknesses including: 0.5 mm 0.75 / 0.8 mm 1.0 mm 1.5 mm 2.0 mm 3.0 mm 4.0 mm 5.0 mm Features Reliable sealing performance Available in standard and custom sizes Good compressibility and recovery Easy installation Helps compensate for minor flange surface irregularities Suitable for general industrial applications Available in non-metallic and metallic reinforced grades Pre-cut design saves fabrication time during installation Applications Pipe flange joints Valves Pumps Heat exchangers Boilers Steam lines Water pipelines Air and gas lines Oil and solvent services, subject to chemical compatibility General industrial equipment Champion Style 20 – Typical Ratings Non-metallic Style 20 Red: Maximum continuous temperature: 380°C Maximum pressure: 35 bar Style 20 Metallic: Steel wire-reinforced construction Maximum continuous temperature: 415°C Maximum pressure: 40 bar Advantages Ready-to-install gasket Custom cutting possible according to flange size Reduces installation time Good sealing reliability Available for water, steam, air, gases and other compatible media Different Champion grades can be selected according to pressure, temperature and service conditions
