SANT FBV2 is a robust forged brass ball valve designed for quick quarter-turn isolation. It has a two-piece construction, full-bore opening, nickel-plated brass ball and stem, and renewable PTFE seats for reliable sealing. Technical Specifications Parameter Specification Model FBV2 Valve Type Ball Valve Construction Two-piece Operation Lever operated Body Material Forged Brass Body Standard IS 6912 FLB Pressure Rating PN25 Port Full Bore Ball Brass, Nickel Plated Stem Machined Brass, Nickel Plated Seat Renewable PTFE Packing PTFE End Connection Female BSP Parallel Screwed Body Test Pressure 40 kg/cm²g hydraulic Working Pressure 25 kg/cm²g hydraulic Materials of Construction Component Material Body Forged Brass – IS 6912 FLB Connector Forged Brass – IS 6912 FLB Ball Forged Brass – IS 6912 FLB, Nickel Plated Stem Brass, Nickel Plated Seat PTFE Gland Seal PTFE Gland Brass Nut Stainless Steel Lever Aluminium Available Sizes SANT lists the FBV2 from ¼“ to 4“: ¼“ / 8 mm ⅜“ / 10 mm ½“ / 15 mm ¾“ / 20 mm 1“ / 25 mm 1¼“ / 32 mm 1½“ / 40 mm 2“ / 50 mm 2½“ / 65 mm 3“ / 80 mm 4“ / 100 mm Key Features Full-bore flow passage Strong forged-brass body Two-piece construction Quick 90° quarter-turn operation Renewable PTFE seats Nickel-plated ball and stem Low-maintenance design Reliable shut-off Female BSP parallel threaded ends Suitable for high-pressure applications up to the specified 25 kg/cm²g working pressure. Typical Applications Water supply lines Plumbing systems HVAC and utility lines Compressed-air systems Industrial utility pipelines General process-fluid isolation Compatible oil and other fluid services, subject to material compatibility Dimensions The SANT FBV2 is available in different face-to-face dimensions depending on size. For example, the approximate LL dimension is 105 mm for ¼“–½“, 128 mm for ¾“–1“, 170 mm for 1¼“–1½“, 210 mm for 2“, and 240 mm for 4“.

The SANT SBBV Brass Balancing Valve is designed for precise hydraulic balancing and flow regulation in piping systems. Its double-regulation arrangement allows controlled adjustment of flow through individual circuits, making it particularly useful in HVAC, chilled-water, heating-water and general water distribution systems. Technical Specifications Parameter Specification Model SBBV Type Precise Balancing, Double Regulation Body Forged Brass Body Standard IS 6912-FLB Disc / Cartridge Brass Stem Brass Bonnet Forged Brass, IS 6912-FLB Regulating Wheel ABS Plastic End Connection Female BSP Parallel Threads Maximum Working Pressure 1.6 MPa / 16 bar / 232 psi Body Test Pressure 2.4 MPa / 24 bar / 348 psi Maximum Working Temperature 150°C Materials of Construction Body: Forged Brass – IS 6912-FLB Bonnet: Forged Brass – IS 6912-FLB Disc/Cartridge: Brass Stem: Brass Regulating Wheel: ABS Plastic Available Sizes SANT lists the SBBV in 20–50 mm (¾“–2“): Size Inch Face-to-Face Dimension 20 mm ¾“ 78 mm 25 mm 1“ 102 mm 32 mm 1¼“ 105 mm 40 mm 1½“ 120 mm 50 mm 2“ 140 mm The regulating-wheel diameter is approximately 75 mm. Key Features Precise flow balancing Double-regulation design Forged brass construction Brass stem and cartridge Adjustable regulating wheel Female BSP parallel threaded ends Suitable for relatively high-temperature water service Compact design Easy manual adjustment Applications HVAC systems Chilled-water systems Hot-water heating systems Fan-coil units Hydronic distribution systems Building services Industrial water circuits Process-water systems Advantages The valve allows the flow in individual branches of a hydronic system to be balanced and regulated, helping distribute water more evenly and improve overall system performance.

The SANT Air Vent Valve is designed to automatically release trapped air from water and utility piping systems. Removing accumulated air helps maintain proper flow, reduce air locking and improve the efficiency of the pipeline. Technical Specifications Parameter Specification Model AV Valve Type Air Vent Valve Body Brass Pressure Rating PN16 Max. Working Temperature 100°C Strainer Stainless Steel Float Plastic Disc Assembly Brass Cover Brass Cap Brass Adaptor Brass Connection Screwed HSN 84818090 Materials of Construction Body: Brass Adaptor: Brass Cover: Brass Cap: Brass Disc Assembly: Brass Float: Plastic Strainer: Stainless Steel Available Sizes SANT lists the AV Air Vent Valve in: ½“ (15 mm) ¾“ (20 mm) 1“ (25 mm) The listed overall dimension F is approximately 73.5 mm for all three sizes. Features Automatic removal of trapped air Compact brass construction Stainless-steel strainer Plastic float mechanism Helps prevent air locking Improves pipeline flow efficiency PN16 pressure rating Suitable for systems operating up to 100°C Simple screwed connection Low-maintenance construction Applications Water supply pipelines Plumbing systems HVAC water circuits Pumping systems Water-treatment plants Industrial utility pipelines Building water-supply systems General water services Advantages SANT AV Air Vent Valve provides automatic air release without external power. The internal float mechanism responds to the presence of air in the valve chamber, allowing trapped air to escape while helping prevent water from continuously discharging.
