An MS Flange (Mild Steel Flange) is a mechanical component used to connect pipes, valves, pumps, and other equipment in a piping system. Flanges provide a strong, leak-proof, and detachable joint, making installation, inspection, and maintenance easy. MS flanges are widely used in water supply, oil & gas, fire fighting, HVAC, fabrication, and industrial piping systems due to their strength, durability, and cost-effectiveness. Material & Construction Material: Mild Steel / Carbon Steel Common Grades: IS 2062 / ASTM A105 Manufacturing: Forged / Plate Cut / Welded Surface Finish: Black, Painted, Galvanized, Powder Coated Types of MS Flanges Slip-On Flange (SOFF / SORF) Weld Neck Flange (WNRF) Blind Flange (BLRF) Socket Weld Flange Threaded Flange Lap Joint Flange Plate Flange Standards & Specifications ANSI / ASME B16.5 BS 10 Table D / E / F / H DIN / IS / JIS Standards Pressure Classes: Class 150 Class 300 Class 600 Class 900 Flange Face Types: Raised Face (RF) Flat Face (FF) Ring Type Joint (RTJ) Size Range Typically from ½” (15 NB) to 48” (1200 NB) Thickness and drilling as per pressure class and standard Key Features ✔ Strong and durable construction ✔ Easy installation and maintenance ✔ Excellent weldability ✔ Cost-effective piping solution ✔ Suitable for high and low pressure systems ✔ Available in multiple drilling standards Applications Water Supply Systems Fire Fighting Pipelines Oil & Gas Industries Chemical & Petrochemical Plants HVAC & Utility Lines Structural & Fabrication Work Steam & Process Piping Advantages Leak-proof pipe connection Easy dismantling for maintenance High mechanical strength Long service life Widely available in various standards and sizes

An MS Bend (Mild Steel Bend) is a pipe fitting used to change the direction of flow in a piping system while maintaining smooth fluid movement. Compared to elbows, bends generally have a larger radius, resulting in lower pressure loss, reduced turbulence, and improved flow efficiency. MS bends are widely used in water supply, steam, oil & gas, fire fighting, HVAC, chemical, and industrial piping systems. Material & Construction Material: Mild Steel / Carbon Steel Grade: IS 2062 / ASTM A234 WPB Manufacturing Type: Hot Formed, Cold Formed, Seamless, or Welded Surface Finish: Black, Painted, Galvanized, Epoxy Coated Types of MS Bends 45° Bend 90° Bend 180° Return Bend Long Radius (LR) Bend Short Radius (SR) Bend 3D Bend 5D Bend 10D Bend (for smooth flow applications) End Connections Butt Weld (BW) Socket Weld (SW) Flanged End (special applications) Standards & Specifications ASME B16.9 – Factory Made Butt Weld Fittings ASME B16.28 – Short Radius Bends DIN / IS Standards Pressure Ratings SCH 20 SCH 40 SCH 80 SCH 160 XXS Size Range ½“ (15 NB) to 48“ (1200 NB) Key Features ✔ High mechanical strength ✔ Smooth flow with reduced pressure drop ✔ Excellent weldability and fabrication properties ✔ Suitable for high-pressure and high-temperature services ✔ Durable and long-lasting performance ✔ Available in various radii and schedules Applications Water Distribution Systems Steam & Boiler Pipelines Oil & Gas Industries Petrochemical Plants Fire Fighting Systems HVAC & Utility Piping Power Plants Structural and Industrial Projects Advantages Lower friction loss compared to sharp elbows Improved flow characteristics Reduced turbulence and vibration Strong and reliable construction Cost-effective piping solution Easy installation and maintenance Common Radius Types Bend Type Radius Short Radius Bend 1D Long Radius Bend 1.5D 3D Bend 3 × Pipe Diameter 5D Bend 5 × Pipe Diameter 10D Bend 10 × Pipe Diameter Why Choose MS Bends? ✔ Excellent flow efficiency ✔ Strong and durable mild steel construction ✔ Suitable for industrial, commercial, and utility piping systems ✔ Available in seamless and welded construction ✔ Reliable performance under demanding operating conditions 👉 Industrial Engineering Syndicate deals in MS Bends, including Long Radius Bends, Short Radius Bends, 3D Bends, 5D Bends, and customized piping bends for industrial applications.

Grooved Pipe Fittings are mechanical piping components designed to connect pipes using a grooved coupling system. Instead of welding or threading, the pipe ends are grooved and joined with a coupling, gasket, and bolts, making installation faster and easier. Grooved fittings are widely used in fire fighting, HVAC, water supply, industrial piping, and utility systems. Material & Construction Material: Ductile Iron (ASTM A536 Grade 65-45-12) Surface Finish: Red Painted Orange Painted Hot-Dip Galvanized Epoxy Coated Gasket Material: EPDM Nitrile (NBR) Silicone Fluoroelastomer (Viton) Types of Grooved Pipe Fittings Grooved Elbow (90° & 45°) Grooved Tee Grooved Reducer Grooved Cross Grooved Cap Grooved Flange Adapter Grooved Coupling (Rigid & Flexible) Grooved Mechanical Tee Grooved U-Bolt Mechanical Tee Standards & Specifications AWWA C606 – Grooved and Shouldered Joints ASTM A536 – Ductile Iron Castings UL Listed & FM Approved (Fire Protection Applications) ISO / ANSI Standards Pressure Rating Up to 300 PSI (20 Bar) depending on fitting type and size Size Range 1“ (25 NB) to 24“ (600 NB) and larger sizes available Key Features ✔ Quick and easy installation ✔ No welding required ✔ Leak-proof gasket sealing system ✔ Easy maintenance and replacement ✔ Absorbs vibration and thermal expansion ✔ Reduces installation time and labor costs ✔ Suitable for rigid and flexible piping systems Applications Fire Fighting Systems Sprinkler Networks HVAC Systems Chilled Water Lines Industrial Process Piping Water Distribution Systems Mining & Utility Pipelines Commercial Buildings Advantages Faster installation than welded systems Lower maintenance costs Easy system expansion and modification Excellent vibration and noise absorption Reliable sealing performance Reduced downtime during repairs Common Sizes Available Size (NB) Inch 25 NB 1“ 32 NB 1¼“ 40 NB 1½“ 50 NB 2“ 65 NB 2½“ 80 NB 3“ 100 NB 4“ 150 NB 6“ 200 NB 8“ Up to 600 NB Up to 24“ Why Choose Grooved Pipe Fittings? ✔ Fast and economical installation ✔ Strong and durable ductile iron construction ✔ Ideal for fire fighting and HVAC applications ✔ Easy maintenance and future system modifications ✔ Reliable leak-proof jointing system 👉 Industrial Engineering Syndicate deals in Grooved Pipe Fittings including couplings, elbows, tees, reducers, flanges, caps, and other grooved piping accessories for fire fighting, HVAC, and industrial applications.
